Adam Audio A7V Black
Key Specs
| Monitor Type & Configuration | Active 2-Way |
|---|---|
| Total Power Output | 130 W RMS |
| Tweeter | 1x 2" / 50.8 mm Ribbon |
| Woofer | 1x 7" / 17.8 cm Composite Cone Voice Coil: 1.3" / 33 mm |
| Audio I/O | 1x XLR 3-Pin Balanced Line Input1x RCA Unbalanced Line Input |
| Digital Audio I/O | No |
| Network I/O | 1x RJ45 Ethernet |
| Wireless | No |
| Number of Included Monitors | Single Monitor |
|---|---|
| Enclosure | Bass-Reflex/Ported, Shielded |
| Total Power Output | 130 W RMS |
| Tweeter | 1x 2" / 50.8 mm Ribbon |
| Woofer | 1x 7" / 17.8 cm Composite Cone Voice Coil: 1.3" / 33 mm |
| Amplifiers | LF: 90 W RMS / 110 W Peak Class-DHF: 15 W RMS / 20 W Peak Class-AB |
Performance
| Frequency Response | 44 Hz to 41 kHz ± 3 dB |
|---|---|
| Maximum Sound Pressure Level (SPL) | 105 dB (Peak) |
Signal Processing
| EQ | 1x HF Shelf 1x HF Notch/Peak 1x Low-Mid Notch/Peak 1x LF Shelf |
|---|---|
| Filters | No |
| Parametric EQ | No |
| Crossover Frequency | 2.8 kHz |
| Maximum Sampling Rate | 96 kHz / 24-Bit |
| Audio I/O | 1x XLR 3-Pin Balanced Line Input1x RCA Unbalanced Line Input |
| Digital Audio I/O | No |
| Network I/O | 1x RJ45 Ethernet |
| USB | No |
| Wireless | No |
| Mobile App Compatible | No |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| Power Consumption | 300 W (Maximum) |
Physical
| Color | Black |
|---|---|
| Monitor Orientation | Vertical or Horizontal |
| Mounting Points | No |
| Dimensions (W x H x D) | 7.9 x 13.3 x 11" / 20 x 33.7 x 28 cm |
| Weight | 19.2 lb / 8.7 kg |
Packaging Info
| Package Weight | 25.65 lb |
|---|---|
| Box Dimensions (LxWxH) | 19.25 x 18.5 x 13.5" |
