Panasonic HC-X1500 UHD 4K HDMI Pro Camcorder
Imaging
| Sensor Resolution | Actual: 8.57 Megapixel Effective: 8.29 Megapixel |
|---|---|
| Sensor Type | 1/2.5"-Type MOS Sensor |
| Image Stabilization | Optical in Integrated Lens |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters |
| Capture Type | Stills & Video |
Exposure Control
| Shutter Type | Not Specified by Manufacturer |
|---|---|
| Shutter Speed | 1/8000 to 1/6 Second |
| Gain | 0 to 30 dB |
| Minimum Illumination | 1.5 Lux at 1/30 Shutter Speed |
| White Balance | 2000 to 15,000K |
Lens
| Focal Length | 4.1 to 98.9mm (35mm Equivalent Focal Length: 25 to 600mm) |
|---|---|
| Optical Zoom Ratio | 24x |
| Max Digital Zoom | 48x |
| Maximum Aperture | f/1.8 |
| Minimum Aperture | f/4 |
| Optical Design | 14 Elements in 11 Groups |
| Minimum Focus Distance | Wide: 0.3' / 0.1 m Telephoto: 3.9' / 1.2 m |
| Filter Size | 62 mm |
| Control Rings | Focus Zoom Iris |
| Focus Control | Autofocus Manual Focus |
Video Capture
| Internal Recording Modes | H.265 Long GOP/MOV 4:2:0 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps (100 to 200 Mb/s VBR) H.264 Long GOP/MOV 4:2:0 8-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps (100 to 150 Mb/s VBR) H.264 Long GOP/MOV 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97 fps (150 Mb/s VBR) 1920 x 1080p at 23.98/25/29.97/50/59.94/100 fps (50 to 100 Mb/s VBR) 1920 x 1080i at 50/59.94 fps (50 to 100 Mb/s VBR) H.264 ALL-Intra/MOV 4:2:2 8-Bit 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (100 to 200 Mb/s VBR) 1920 x 1080i at 50/59.94 fps (100 Mb/s VBR) H.265 Long GOP/MP4 4:2:0 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps (72 to 100 Mb/s VBR) H.264 Long GOP/MP4 4:2:0 8-Bit 3840 x 2160 at 23.98/25/29.97 fps (50 to 72 Mb/s VBR) 1920 x 1080p at 23.98/50/59.94 fps (50 Mb/s VBR) AVCHD 4:2:0 8-Bit 1920 x 1080p at 23.98/50/59.94 fps (21 to 25 Mb/s VBR) 1920 x 1080i at 50/59.94 fps (17 to 21 Mb/s VBR) 1280 x 720 at 50/59.94 fps (8 Mb/s VBR) |
|---|---|
| Fast-/Slow-Motion Support | Yes |
| Built-In Microphone Type | Stereo |
| Audio Recording | MOV: 2-Channel 24-Bit LPCM Audio MP4: 2-Channel 24-Bit AAC Audio AVCHD: 2-Channel 24-Bit AC-3 Audio |
| IP Streaming | RTMP, RTP, RTSP 320 x 180 to 1920 x 1080 at 25p, 30p, 50p, 60p (0.5 to 24.00 Mb/s) |
Still Image Capture
| Image File Format | JPEG |
|---|
Interface
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-I) (U3/V30 or Faster Recommended) |
|---|---|
| Video I/O | 1 x HDMI Output |
| Audio I/O | 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x Barrel (12VDC) Input |
| Other I/O | 1 x Micro-USB Input 1 x 2.5 mm Sub-Mini Output |
| Wireless | 2.4 GHz Wi-Fi 4 (802.11n) |
| Mobile App Compatible | Yes: Android & iOS App Name: HC ROP Functionality: Remote Control *As of December, 2022: Check with manufacturer for the most up-to-date compatibility |
| Global Positioning (GPS, GLONASS, etc.) | None |
Monitor
| Size | 3.5" |
|---|---|
| Resolution | 2,760,000 Dot |
| Display Type | Articulating Touchscreen LCD |
Viewfinder
| Type | Built-In Electronic (LCD) |
|---|---|
| Size | 0.24" |
| Resolution | 1,560,000 Dot |
Focus
| Focus Type | Auto and Manual Focus |
|---|---|
| Focus Mode | Automatic, Manual Focus |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
|---|---|
| Operating Humidity | 10 to 80% |
General
| Battery Type | Panasonic AG-VBR Series |
|---|---|
| Power Consumption | 7.9 W |
| Tripod Mounting Thread | 1/4"-20 Female |
| Accessory Mount | 1 x Intelligent Hot Shoe |
| Built-In Video Light | No |
| Dimensions (W x H x D) | 10.1 x 5.1 x 3.7" / 257 x 129 x 93 mm (Without Handle) |
| Weight | 2.65 lb / 1.2 kg |
Packaging Info
| Package Weight | 5.05 lb / 2.29 kg |
|---|---|
| Box Dimensions (LxWxH) | 12.8 x 11.1 x 8.38" |
Identifiers
| MPN | HC-X1500E |
|---|---|
| GTIN / EAN / UPC | 5025232935147 |
