Panasonic AG-DVX200 4K Camcorder with Four Thirds Sensor and Integrated Zoom Lens
Imaging
| Sensor Resolution | Effective: 15.49 Megapixel (1920 x 1080) |
|---|---|
| Sensor Type | 4/3" MOS Sensor |
| Image Stabilization | Digital |
| Built-In ND Filter | Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters |
| Shutter Speed | 1/60 to 1/2000 sec (In 60p/60i Mode) |
| Shutter Angle | 3 to 360° in 0.5° Increments |
| Precise Scan Rate Control | Yes |
| Gain | 0 to 24 dB 30 to 36 dB (Expanded) |
| White Balance | 2000 to 15,000K |
Lens
| Focal Length | 12.8 to 167mm (35mm Equivalent Focal Length: 28 to 365.3mm) |
|---|---|
| Optical Zoom Ratio | 13x |
| Maximum Aperture | f/2.8 |
| Minimum Aperture | f/4.5 |
| Minimum Focus Distance | Wide: 39.4" / 1.0 m |
| Filter Size | 72 mm |
| Control Rings | Focus Zoom Iris |
| Focus Control | Autofocus Manual Focus |
Recording
| Recording Modes | MOV/MP4 4:2:0 8-Bit: 3840 x 2160p at 23.98/25/29.97 fps (100 Mb/s) 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (50 to 200 Mb/s) MOV 4:2:0 8-Bit: 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (8 Mb/s) |
|---|---|
| Variable Frame Rates | 1080p: 2 to 120 fps |
| Audio Recording | MOV: 2-Channel 16-Bit 48 kHz LPCM Audio MP4: 2-Channel 16-Bit 48 kHz LPCM Audio AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio |
| Still Image Support | Not Specified by Manufacturer |
| IP Streaming | None |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-I) (128 GB Maximum) Dual Slot: SD/SDHC (UHS-I) (32 GB Maximum) |
| Video Connectors | 1 x BNC (3G-SDI) Output 1 x HDMI (HDMI 2.0) Output |
| Audio Connectors | 2 x 3-Pin XLR Input 1 x 1/8" / 3.5 mm Stereo Line Level Output 1 x 1/8" / 3.5 mm Stereo Headphone Output |
| Other I/O | 1 x 2.5 mm LANC Control Input 1 x 3.5 mm LANC Control Input 1 x BNC Timecode Data Input/Output 1 x USB Type-A USB 3.1 Gen 1 Data Input/Output 1 x USB Micro-B USB 3.1 Gen 1 Data, Video Output |
| Size | 4.3" |
| Resolution | 2,760,000 Dot |
| Display Type | Articulating Touchscreen LCD |
EVF
| EVF Display Type | OLED |
|---|---|
| Screen Size | .39" |
| EVF Resolution | 1,770,000 Dots |
Power
| Battery Type | Panasonic AG-VBR Series |
|---|---|
| Power Connectors | 1 x Barrel (11.4 to 12.6 VDC) Input |
| Power Consumption | 21.7 W |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
|---|---|
| Operating Humidity | 10 to 80% |
| Accessory Mount | 1 x 1/4"-20 Female 1 x Cold Shoe Mount |
| Dimensions | 14.7 x 8.5 x 7.1" / 374 x 216 x 181 mm (Without Protrusions) |
| Weight | 6 lb / 2.7 kg |
Packaging Info
| Package Weight | 12.7 lb / 5.76 kg |
|---|---|
| Box Dimensions (LxWxH) | 19.1 x 14.8 x 11.2" |
