Canon XA40 Professional UHD 4K Camcorder
Imaging
| Sensor Resolution | Actual: 21.14 Megapixel (5352 x 3950) Effective: 8.92 Megapixel (3840 x 2160) |
|---|---|
| Sensor Type | 1/2.3" CMOS Sensor |
| Image Stabilization | Optical in Integrated Lens Digital |
| Shutter Speed | 1/1 to 1/2000 sec |
| Gain | 0 to 24 dB (Native) |
| Signal-to-Noise Ratio | 3 dB |
| Minimum Illumination | 5 Lux at 1/30 Shutter Speed 0.3 Lux at 1/2 Shutter Speed |
| White Balance | 2000 to 15,000K |
Lens
| Focal Length | 3.6 to 73.4mm (35mm Equivalent Focal Length: 29.3 to 601mm) |
|---|---|
| Optical Zoom Ratio | 20x |
| Maximum Aperture | f/1.8 to 2.8 |
| Minimum Focus Distance | Wide: 0.4" / 1.0 cm Entire Zoom Range: 23.6" / 60.0 cm |
| Filter Size | 58 mm |
| Focus Control | Autofocus Manual Focus |
Recording
| Recording Modes | H.264/MP4: 3840 x 2160p at 23.98/24/29.97/30 fps (150 Mb/s) 1920 x 1080p at 23.98/24/29.97/30/59.94/60 fps (17 to 35 Mb/s) 1280 x 720p at 59.94/60 fps (8 Mb/s) |
|---|---|
| Audio Recording | MP4: 2-Channel 16-Bit AAC Audio MP4: 4-Channel 16-Bit LPCM Audio |
| IP Streaming | Yes |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-I) |
| Video Connectors | 1 x Mini-HDMI (HDMI 2.0) Output |
| Audio Connectors | 2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm Stereo Headphone Input 1 x 1/8" / 3.5 mm Stereo Mic Level Input |
| Built-In Microphone Type | Stereo |
| Other I/O | 1 x USB Mini-B 1 x 2.5 mm |
| Size | 3.0" |
| Resolution | 460,000 Dot |
| Display Type | Articulating Touchscreen LCD |
EVF
| EVF Display Type | LCD |
|---|---|
| Screen Size | .24" |
| EVF Resolution | 1,560,000 Dots |
Power
| Battery Type | Canon BP-8 Series |
|---|---|
| Power Connectors | 1 x Proprietary (8.4 VDC) Input |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C (Recommended) |
|---|---|
| Storage Temperature | 23 to 113°F / -5 to 45°C |
| Operating Humidity | 85% |
| Storage Humidity | 60% |
| Accessory Mount | 1 x Cold Shoe Mount |
| Tripod Mounting Thread | 1/4"-20 Female |
| Dimensions | 7.2 x 4.3 x 3.3" / 18.29 x 10.92 x 8.38 cm (Without Protrusions) 9.1 x 4.5 x 3.3" / 23.11 x 11.43 x 8.38 cm (With Protrusions) |
| Weight | 1.6 lb / 725.74 g |
Packaging Info
| Package Weight | 4.65 lb / 2.11 kg |
|---|---|
| Box Dimensions (LxWxH) | 11 x 10.5 x 8.5" |
