Yamaha MG12 Audio Mixer 12 Channels

Name: Yamaha MG12 Audio Mixer 12 Channels
Brand: Yamaha
SKU: MG12
Price: 351.16 EUR
Availability: OutOfStock

✔ 6x Mic Inputs
✔ 12x Line Inputs
✔ XLR and TRS 1/4″ Stereo Outs
✔ 2x Group Buses
✔ TRS Monitor Outs
✔ 2x Aux Sends
✔ D-PRE Mic Preamps with 48V Phantom
✔ HPF & 3-Band EQ on Channels 1-8
✔ 1/4″ Headphone Output with Level Control
✔ PAD & 1-Knob Compressor on Channels 1-4

351,16€

Out of stock

Description

Yamaha MG12 Audio Mixer 12 Channels

Phantom Power	+48 V switchable, channels 1 - 8
Input Channels	4x mono [mic/line] 2x mono/stereo [mic/line] 2x stereo [line]
Output Channels	2x stereo out 1x monitor out 1x headphone out 2x aux out 2x group out
Bus	Stereo: 1 AUX: 2 GROUP: 2
Pad	26 dB (mono)
HPF	80 Hz, 12 dB/oct (mono/stereo: MIC only)
Compressor	Threshold: +22 dBu to -8 dBu Ratio: 1:1 to 4:1 Output level: 0 dB to 7 dB Attack time: approx. 25 msec Release time: approx. 300 msec
Equalizer	EQ high gain: +15 dB/-15 dB, Frequency: 10 kHz shelving EQ mid gain: +15 dB/-15 dB, Frequency: 2.5 kHz peaking EQ low gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
LED	Peak LED turns on when post EQ signal reaches 3 dB below clipping
Level Metering	2 x 12 - segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB]
Total Harmonic Distortion	0.03 % @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min, 0.005 % @ +24 dBu (1 kHz), GAIN knob: Min
Frequency Response	+0.5 dB/-1.5 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min
Equivalent Input Noise	-128 dBu (mono input channel, Rs: 150 Ω, GAIN knob: max)
Residual Output Noise	-102 dBu (STEREO OUT, STEREO master fader: min)
Crosstalk	-78 dB
Power Requirement	AC 100 - 240 V, 50 / 60 Hz
Power Consumption	22 W
Dimensions	12.1 x 4.6 x 16.6" (308 x 118 x 422 mm)
Net Weight	8.8 lb (4.0 kg)

Packaging Info

Package Weight	12.65 lb
Box Dimensions (LxWxH)	19.1 x 15.5 x 8"
