Panasonic AJ-PX270 microP2 Pihuarvuti AVC-ULTRA HD Videokaamera
Imaging
| Sensor Resolution | Effective: 2.2 Megapixel |
|---|---|
| Sensor Type | 3-Chip 1/3" MOS Sensor |
| Built-In ND Filter | Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters |
| Minimum Illumination | 0.02 Lux at 1/1 Shutter Speed |
Lens
| Focal Length | Not Specified by Manufacturer |
|---|---|
| Optical Zoom Ratio | 22x |
Recording
| Recording Modes | AVC-Intra: 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (50 to 100 Mb/s) AVC-LongG: 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (12 to 50 Mb/s) |
|---|---|
| IP Streaming | None |
| Media/Memory Card Slot | Dual Slot: microP2 Single Slot: P2 Single Slot: SD/SDHC/SDXC |
| Video Connectors | 1 x BNC (3G-SDI) Output 1 x BNC (Composite) Output |
| Audio Connectors | 2 x 3-Pin XLR Input 1 x 1/8" / 3.5 mm Stereo Headphone Output |
| Other I/O | 1 x BNC Timecode Input 1 x BNC Genlock Input 1 x 2.5 mm Camera Interface Control Input 1 x 3.5 mm Camera Interface Control Input |
| Size | 3.5" |
| Resolution | 1,560,000 Dot |
| Display Type | Articulating LCD |
EVF
| EVF Display Type | OLED |
|---|---|
| Screen Size | .5" |
| EVF Resolution | 1,760,000 Dots |
Power
| Battery Type | Panasonic CGA-D54 |
|---|---|
| Accessory Mount | None |
| Dimensions | 6.9 x 6.7 x 13" / 176 x 171 x 329 mm |
| Weight | 5.7 lb / 2.6 kg |
Packaging Info
| Package Weight | 11.65 lb / 5.28 kg |
|---|---|
| Box Dimensions (LxWxH) | 19.1 x 14.8 x 12.8" |
