Teltonika TAT100 GPS Tracker Asset
Connectivity & Networks
| Cellular Technology | 2G GSM / GPRS (Quad-band 850/900/1800/1900 MHz) |
|---|---|
| GNSS Positioning | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS |
| Tracking Sensitivity | -165 dBM |
| Antennas | Internal High Gain GNSS and GSM antennas |
| Bluetooth Profile | Bluetooth 4.0 + LE (Supports EYE Beacons and EYE Sensors) |
Power & Battery Life
| Battery Type | 2x 2200mAh Li-SOCl2 extremely low self-discharge batteries (3.6V, Interchangeable) |
|---|---|
| Total Capacity | 4400 mAh |
| Battery Lifespan | Up to 3 years (based on sending 1 location record per day) |
Hardware & Smart Scenarios
| Integrated Sensors | 3-axis Accelerometer |
|---|---|
| Internal Memory | 128MB Flash |
| SIM Slot Type | Micro-SIM or internal eSIM option |
| Configuration Port | Micro-USB 2.0 |
| Advanced Scenarios | Enhanced Tamper Detection, Accelerometer Wake-up, Geo-fence, Over Speeding, Offline Tracking |
Physical Properties
| Dimensions (LxWxH) | 78 x 63 x 28 mm |
|---|---|
| Net Weight | 117 g |
| Ingress Protection | IP68 Rating (Fully dust-tight and waterproof up to 1.5 meters) |
| Operating Temperature | -35°C to +75°C |
Identifiers
| MPN | TAT100TSBAB0 |
|---|---|
| GTIN / EAN / UPC | 4779027312897 |
