UBIQUITI UniFi 5G Max Outdoor Ethernet LAN (RJ-45) ports 1 MU-MiMO No PoE in
Ubiquiti UniFi 5G Max Outdoor White EU
| Brand | Ubiquiti |
|---|---|
| Product Series | UniFi |
| Model | 5G Max Outdoor |
| MPN | U5G-Max-Outdoor |
| EAN | 810177162803 |
| Product Type | Outdoor 5G Cellular Modem |
| Device Category | Cellular Network Device |
| Color | White |
| Regional Version | EU |
| Mobile Network Support | 5G NR, 4G LTE and 3G UMTS |
| 5G Technology | Sub-6 GHz 5G NR, NSA and SA |
| Maximum 5G NSA Download Speed | 3.4 Gbps |
| Maximum 5G NSA Upload Speed | 560 Mbps |
| Maximum 5G SA Download Speed | 1.8 Gbps |
| Maximum 5G SA Upload Speed | 650 Mbps |
| Maximum 4G LTE Download Speed | 1.6 Gbps |
| Maximum 4G LTE Upload Speed | 210 Mbps |
| 5G Frequency Bands | n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79 |
| 4G LTE Frequency Bands | B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71 |
| 3G UMTS Frequency Bands | B1, B2, B4, B5, B8, B19 |
| SIM Card Slots | 1 Nano-SIM slot |
| Additional SIM Support | Nano-SIM or eSIM, depending on configuration |
| Dual SIM Support | Supported for failover configurations |
| Wi-Fi | No |
| Ethernet LAN Ports | 1 × RJ-45 |
| Ethernet Interface | 2.5 Gigabit Ethernet |
| PoE Input | Yes |
| Power Method | Power over Ethernet (PoE) |
| Maximum Power Consumption | 14.5 W |
| MU-MIMO | No |
| Cellular Antennas | 6 integrated cellular antennas |
| High-Gain Antennas | 2 integrated directional antennas for downlink |
| Peak Antenna Gain | 9 dBi |
| Antenna Beamwidth | 85° × 85° |
| Outdoor Installation | Yes |
| Mounting Options | Pole mount and wall mount |
| Mounting Hardware | Included |
| Weather Resistance | IPX6; IP67 with compatible cable-gland door kit |
| Enclosure Material | Aluminium alloy and UV-stabilized polycarbonate |
| Mount Material | UV-stabilized polycarbonate |
| Pole Diameter Compatibility | 25–63.5 mm |
| Wind Loading | 91 N at 200 km/h |
| Management | Ethernet through UniFi Network |
| Compatibility | Compatible UniFi consoles and Cloud Gateways |
| Factory Reset Button | Yes |
| LED Indicators | Yes |
| Remote SIM | Planned feature; availability depends on software release |
| Operating Temperature | -40°C to 65°C |
| Operating Humidity | 5–95%, non-condensing |
| Maximum Cellular Transmit Power (5G) | 26 dBm |
| Maximum Cellular Transmit Power (4G) | 25 dBm |
| Certifications | CE, GCF and PTCRB, with regional approvals |
| NDAA Compliant | Yes |
| Device Dimensions (H × W × D) | 22 × 16.5 × 6.69 cm |
| Dimensions with Mount (H × W × D) | 22 × 16.5 × 12.2 cm |
| Device Weight | 1.2 kg |
| Mount Weight | 130 g |
| Product Weight | 1.2 kg, excluding mount |
| Included Accessories | Outdoor cellular modem, mounting hardware and documentation; power supply availability depends on package configuration |
| Packaging Weight | 0.474 kg |
| Packaging Dimensions | 2.65 × 10.9 × 18 cm(H × W × L) |
Identifiers
| MPN | U5G-Max-Outdoor |
|---|---|
| GTIN / EAN / UPC | 810177162803, 0810177162803 |
