Teltonika TRB145 CAT1 LTE 4G Gateway
Cellular & Networking
| Mobile Technology | 4G LTE Cat 1 (with 3G and 2G fallback) |
|---|---|
| LTE FDD Bands | B1 / B3 / B7 / B8 / B20 / B28A |
| Network Protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL/TLS, MQTT |
| SIM Slot Type | 1x Mini-SIM (2FF) |
Hardware Interfaces
| Serial Port | 1x RS485 (7-pin industrial terminal block) |
|---|---|
| Configuration Port | 1x Micro-USB 2.0 |
| Antenna Connector | 1x SMA for Mobile |
| Configurable I/O | 2x Digital Input/Output (on power socket) |
System & Processor
| Processor (CPU) | ARM Cortex-A7, 1.2 GHz |
|---|---|
| System Memory (RAM) | 128 MB, DDR3 |
| Storage Flash | 512 MB, SPI Flash |
| Operating System | RutOS (OpenWrt based Linux OS) |
Power & Physical
| Input Voltage Range | 9 - 30 V DC (4-pin industrial socket) |
|---|---|
| Casing Material | Anodized Aluminum Shell |
| Dimensions (WxHxD) | 74.4 x 25 x 64.4 mm |
| Net Product Weight | 130 g |
| Ingress Protection | IP30 Rating |
Identifiers
| MPN | TRB145 |
|---|---|
| GTIN / EAN / UPC | 4779027312415 |
