Dell Pro Dock WD25Z DisplayPorts quantity 2 HDMI ports quantity 1 Black

Name: Dell Pro Dock WD25Z DisplayPorts quantity 2 HDMI ports quantity 1 Black
Brand: Dell
SKU: 1646750
Price: 214.27 EUR
Availability: BackOrder

✔LED Power Indicator
✔Supported configurations depend on connected displays
✔Supports two-, three- and four-display configurations
✔Dock power button with system synchronization

214,27€

Prijs is inclusief 21% btw

Op bestelling leverbaar (levering binnen 3 - 4 werkdagen)

Achteraf betalen

Koop nu en betaal binnen 30 dagen.

Betaal in 3 gelijke termijnen 3 × 71,42€

Spreid je betaling over 3 maanden.

Maandbedrag vanaf 10,62€

Bevestig je aankoop snel en gemakkelijk en betaal in termijnen.

2 jaar garantie

Gratis retour voor garantieservice

14 dagen bedenktijd

Veilig betalen

Beschrijving

Dell Pro Dock WD25Z DisplayPorts quantity 2 HDMI ports quantity 1 Black

General

Product Name	Dell Pro Dock WD25Z
Manufacturer Part	4JD4W
Dell Part Number	210-BTMQ
Product Type	USB-C docking station
Connectivity Technology	Wired
Supported Devices	Notebook, Desktop PC
Host Interface	USB Type-C
Number of Displays Supported	Up to 4 external displays

Video

DisplayPort Quantity	2
DisplayPort Version	DisplayPort 1.4
HDMI Port Quantity	1
HDMI Version	HDMI 2.1
USB-C DisplayPort	1 x USB-C 3.2 Gen 2 Multi-Function DisplayPort 1.4
Maximum Displays	4
Maximum Resolution	Up to 6144 x 3456 (6K) at 60Hz
Supported Resolutions	1280 x 1024, 1920 x 1080, 2560 x 1440, 3840 x 2160, 3440 x 1440, 5120 x 2160, 6144 x 3456
Display Modes	FHD @ 60Hz, QHD @ 60Hz, 4K @ 60Hz, WQHD @ 60Hz, 5K @ 60Hz, 6K @ 60Hz, SXGA @ 60Hz
Quad Display	Supported up to SXGA @ 60Hz depending on configuration

USB

Total USB Ports	6
USB-A Quantity	4
USB-A Specification	USB 3.2 Gen 2, 10 Gbps
USB-C Data Quantity	1
USB-C Data Specification	USB 3.2 Gen 2, 10 Gbps
USB-C Multi-Function Quantity	1
USB-C Multi-Function Specification	USB 3.2 Gen 2 with DisplayPort 1.4 Alt Mode
Maximum Data Transfer Rate	10 Gbps per USB 3.2 Gen 2 data interface

Power

Power Supply Wattage	180W maximum
Power Delivery	130W for compatible Dell systems
Power Delivery	96W for non-Dell systems
USB-A Power Output	4.5W per USB-A port
USB-C Data Port Power	15W
USB-C Multi-Function Power	7.5W
Power Source	External power adapter
Power Delivery Pass-through	Yes

Network

Ethernet Port	1 x RJ-45
Ethernet Speed	10/100/1000/2500 Mbps
Ethernet Standard	2.5GbE
Wake-on-LAN	Supported on compatible systems
MAC Address Pass-through	Supported on selected Dell and compatible systems

Management

MAC Address Pass-through	Supported
PXE Boot	Supported
Dock Power Button Sync	Supported
Wake-on-LAN	Supported
WLAN to LAN Switch	Supported
Kernel DMA Protection	Supported
Port Disablement	Supported
Firmware Updates	Host PC-based firmware update and firmware update on disconnect
Management Software	Dell Firmware Utility, Dell Display and Peripheral Manager, Dell Command Update
Cloud Management	Dell Device Management Console supported via host PC software

Security

Security Slot	Kensington Security Slot and Noble Wedge Security Slot
DMA Protection	Kernel Direct Memory Access (DMA) Protection

Connectivity

Video Interfaces	2 x DisplayPort 1.4, 1 x HDMI 2.1, 1 x USB-C Multi-Function DisplayPort 1.4
USB Interfaces	4 x USB-A 3.2 Gen 2, 1 x USB-C 3.2 Gen 2, 1 x USB-C 3.2 Gen 2 Multi-Function DisplayPort
Network Interface	1 x RJ-45 2.5GbE
Host Connection	USB Type-C
Cable Length	2.95 ft (approx. 0.9 m)

Audio

Audio Output	Audio support through compatible USB-C/display connections
3.5mm Audio Jack	Not specified by Dell for WD25Z

Features

LED Power Indicator	Yes
Indicator Light	Yes
Power Button	Dock power button with system synchronization
Multi-Display Support	Supports two-, three- and four-display configurations
DisplayPort Daisy Chaining	Supported configurations depend on connected displays and system capabilities

Operating System

Windows	Windows 10, Windows 11
Linux	Ubuntu 24.04, Red Hat Enterprise Linux 9.6
ChromeOS	ChromeOS 137
Compatibility	Compatibility depends on host system, USB-C capabilities and operating system

Physical

Height	35.3 mm
Width	205 mm
Depth	90 mm
Weight	Approx. 550 g

Warranty

Standard Warranty	3-Year Limited Hardware Warranty with Advanced Exchange
Extended Warranty	Optional 4- and 5-year warranty available

Package Contents

Dock	1 x Dell Pro Dock WD25Z
Power Adapter	1 x Power Adapter
Power Cord	1 x Power Cord
Documentation	Quick Start Guide, Safety, Environmental and Regulatory Information

Identifiers

MPN	210-BTJB
GTIN / EAN / UPC	5397321029045
